Guide compact du Système de réfrigération Sub-Zero Designer (anciennement appelé intégré)

[Music] Integrated Refrigeration Quickstart. The control panel for integrated refrigeration is located on the top section of the tall units and in a top drawer of the drawer units. Here an ultra-smart microprocessor controls all electronic functions, including temperature, adaptive defrost, lights, and cooling fan. Also all integrated Sub Zero units feature a unit on/off keypad, which means you never have to shut off power at the circuit breaker when your unit is being serviced or when you're away from home for extended periods. The LCD display that you easily adjust and monitor all temperature zones in the unit. For refrigerator/freezer combination units the control panel features two sets of warmer and colder keypads. To adjust the temperature in either section simply depress the appropriate keypad. The refrigerator requires 24 hours to reach the temperature you set. Note: your unit is preset at 38 degrees in the refrigerator and zero degrees in the freezer. The control panel also features an ice on off keypad for units with an icemaker. The ice maker in your subzero freezer is fully automatic. To start making ice just press ice on. When the ice maker is on the word ice will be illuminated. If there's a temperature or icemaker problem, you'll be alerted by a flashing service indicator light. The same service light will also flash if the condenser needs cleaning. Your Sub-Zero Built-In Refrigerator Freezer also lets you know if there's a problem. For example, your unit features an alarm that beeps if the door is ajar. The alarm will sound after 30 seconds and can be deactivated by depressing the bell on/off key pad. When the alarm is activated a bell symbol will be visible in the display panel.
